AMD Ryzen 9 7950X3D CPU, AM5, 4.2GHz (5.7 Turbo), 16-Core, 120W, 144MB Cache, 5nm, 7th Gen, Radeon Graphics, NO HEATSINK/FAN
Condition: New product
19 Items
Data sheet
Manufacturer Number: | 100-100000908WOF |
Manufacturer: | AMD |
Note: | Due to the different monitor and light effects, the actual color of the item might be slightly different from the color shown in the pictures. As for the dimensions, due to the measuring, please allow measuring deviations. Thank you! |
Warehouse: | UK warehouse. Due to operating from different serviced warehouses, we cannot guarantee multiple items from the same order will be delivered together, although we try our best to do this. |
More info
Socket
AM5
Type
AMD Ryzen 9
Clock Speed
4.2GHz
Turbo Speed
5.7GHz
Cores
16 Core
Core Size
CPU Cores: TSMC 5nm FinFET
I/O Die; TSMC 6nm FinFET
I/O Die; TSMC 6nm FinFET
Threads
32
Cache
L1 Cache: 1MB
L2 Cache: 16MB
L3 Cache: 128MB
L2 Cache: 16MB
L3 Cache: 128MB
TDP
120W
Graphics
Yes
Graphics Details
AMD Radeon Graphics
Graphics Core Count: 2
Graphics Frequency: 2200 MHz
GPU Base: 400 MHz
USB Type-C DisplayPort Alternate Mode support
Graphics Core Count: 2
Graphics Frequency: 2200 MHz
GPU Base: 400 MHz
USB Type-C DisplayPort Alternate Mode support
Memory
Memory Channels: 2
Max. Memory: 128GB
System Memory Subtype: UDIMM
Max Memory Speed
1x1R - 5200 MT/s
1x2R - 5200 MT/s
2x1R - 3600 MT/s
2x2R - 3600 MT/s
Max. Memory: 128GB
System Memory Subtype: UDIMM
Max Memory Speed
1x1R - 5200 MT/s
1x2R - 5200 MT/s
2x1R - 3600 MT/s
2x2R - 3600 MT/s
Max PCI Express Lanes
28/24 (Total/Usable)
Additional Usable PCIe Lanes from Motherboard:
AMD X670E: 12x Gen4
AMD X670: 12x Gen4
AMD B650E: 8x Gen4
AMD B650: 8x Gen4
Additional Usable PCIe Lanes from Motherboard:
AMD X670E: 12x Gen4
AMD X670: 12x Gen4
AMD B650E: 8x Gen4
AMD B650: 8x Gen4
Cooler
No
Special Features
AMD 3D V-Cache technology
AMD EXPO Technology
AMD Ryzen Technologies
AMD EXPO Technology
AMD Ryzen Technologies
Package Type
Retail
Package Weight
0.0500 kg
Warranty
3 Years
Full Box Quantity
4
Manufacturer Link
