TP-LINK (EAP110) Omada 300Mbps Wireless N Ceiling Mount Access Point, Passive PoE, 10/100, Free Software

Condition: New product

N300 Wireless N Ceiling Mount Access Point

Free cloud centralized management and Omada app for ultra convenience and easy management
Supports passive PoE for convenient installation up to 100meters2
Ceiling mounting design with chassis makes it easy to deploy on a wall or ceiling
The captive portal provides modern and professional user sign-in experience
Facebook check-in and SMS authentication expands your social exposure with secured technology
Multi-SSID divides multiple wireless networks for different user groups
Enterprise class Wi-Fi security help to decrease network security threats
Supports management VLAN for an enhanced network management

Flexible Placement - Easy mounting design and PoE

The EAP’s elegant appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 supports Passive PoE to make deployment effortless and flexible.

Free Cloud Centralized Management - Anytime, Anywhere

Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.

Efficient Guest Authentication with Facebook and SMS Support

Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.

Easy Management with the Omada App

Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

Compatibility

Omada EAP110 supports 802.11 b/g/n products

Load Balance

Load balance ensures large numbers of users have smooth network experiences in large business networks

Multiple Operating Modes

Multiple operating modes satisfy different application conditions including Managed AP and standalone AP modes

Enterprise Hardware

With Qualcomm Atheros 560MHz chipsets, EAP ensures incredible wireless coverage and reliability

Dustproof design

Prevents dust from dropping onto the PCB through bypass louver, which ensures long-term, unhindered operation.

LSOH Material

Adopts Low Smoke Zero Halogen (LSOH) materials for UL2043 compliance

19 Item Items Warning: Last items in stock!

£ 42.78

Quantity

Data sheet

Note:	Due to the different monitor and light effects, the actual color of the item might be slightly different from the color shown in the pictures. As for the dimensions, due to the measuring, please allow measuring deviations. Thank you!
Manufacturer Number:	EAP110
Manufacturer:	TP-LINK
Warehouse:	UK warehouse. Due to operating from different serviced warehouses, we cannot guarantee multiple items from the same order will be delivered together, although we try our best to do this.

More info

Primary Function

Access Point

Bands

N/A

Max Wireless Transfer Rate

300 Mbps

Max Wired Transfer Rate

10/100 Mbps

Interface(s)

1 x 10/100 Ethernet (RJ-45) Port (Support Passive PoE)

Wireless Standards

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Antenna(s)

Internal 2 x 4dBi omni-directional

Button(s)

Reset

Power Supply

24V Passive PoE
(+4,5pins; -7,8pins. PoE Adapter Included)

Power Consumption

2.8 W

Dimensions

189.4 x 172.3 x 29.5 mm

Weatherproof

Frequency

2.4-2.4835GHz

Reception Sensitivity

300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER

Wireless Functions

Multiple SSIDs (Up to 8 SSIDs)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control
QoS(WMM)
Load Balance
Wireless Schedule
Wireless Statistics based on SSID/AP/Client

Wireless Security

Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

Management

See manufacturers link (next to product images)

Advanced Functions

See Overview

Package Contents

Access Point EAP110
Passive PoE Adapter
Power Cord
Mounting Kit
Installation Guide

Package Type

Retail

Package Weight

0.7600 kg

Warranty

Limited Lifetime
