Asus IPMI Expansion Card w/ Dedicated Ethernet Controller, VGA Port, PCIe 3.0 x1 & ASPEED AST2600A3 OEM Packaging

Condition: New product

ASUS IPMI expansion card with dedicated Ethernet controller, VGA port, PCIe 3.0 x1 interface and ASPEED AST2600A3 chipset to provide the intelligence for IPMI architectures

IPMI 2.0 compliant
Out-of-band and in-band remote management with ASPEED AST2600A3 chipset
Sensor monitoring with notifications of potentially dangerous readings or failure
Control and monitoring of up to 8 chassis fans
BIOS and BMC firmware update via web console or Linux tool
Monitoring of power supply unit voltage and temperature

Remote Management

This ASUS IPMI expansion card delivers a breakthrough remote management solution for motherboards that have overclocking capabilities but not an onboard baseboard management controller (BMC). It benefits applications ranging from financial market trading for high-performance systems, to remote monitoring and real-time troubleshooting.

Accurate Fan Control

To provide real-time system temperature and dynamic fan-curve adjustments for lower fan power consumption, customizable settings for a given temperature source deliver more accurate results to control the rotational speeds of up to eight chassis fans.

* It requires the BMC header on the expansion card to connect the motherboard to be able to set one of motherboard sensors as a temperature source.

Real-time Hardware Monitoring

Multiple embedded sensors detect the real-time status of devices across an internal network, including temperatures, fan speeds and voltages, empowering system administrators to identify failures and reduce outage risks through efficient troubleshooting delivery.

* It requires the BMC header on the expansion card to connect the motherboard to be able to read real-time sensor data. Otherwise, it only captures data from the power-on self-test.

Remote Power Control

System administrators can remotely monitor the power status of multiple devices at once to quickly turn them on or off, cycle power, or initiate hard resets. This can both reduce friction in the IT workflow and deliver energy cost savings.

Multiple Management Interfaces

Multiple management interfaces are available to give IT admins flexible options to manage devices remotely. The web console is straightforward, with a user-friendly interface to quickly access common features. Meanwhile, admins who prefer a text-based interface can also interact with IPMI-enabled devices via the command prompt.

42 Item Items Warning: Last items in stock!

£ 142.44

Quantity

Data sheet

Manufacturer Number:	90MC0AH0-MVUBY1
Manufacturer:	ASUS
Note:	Due to the different monitor and light effects, the actual color of the item might be slightly different from the color shown in the pictures. As for the dimensions, due to the measuring, please allow measuring deviations. Thank you!
Warehouse:	UK warehouse. Due to operating from different serviced warehouses, we cannot guarantee multiple items from the same order will be delivered together, although we try our best to do this.

More info

Chipset

ASPEED AST2600A3

Interface

PCIe 3.0 x1

Internal RAM

System: 384MB
Video: 64MB

Internal ROM

64MB

Timers

32-bit Watchdog Timer

Features

Sensor monitoring and reporting when exceeding thresholds/failure
Fan and PSU monitoring and faillure alerting
IPMI 2.0 compliant
Cold boot
HTML5 Virtual Console (no Java)
SOL Support
SSH (SMASH 2.0) support
SNMP V3 Alerting
Update BIOS, BMC firmware via Web console or Linux tool
BIOS setting changing
Component Inventory Management

*Some of key features requires cable connection from this card to motherboard or PSU. For more details, please refer to user manual

Graphics

1 x D-sub supports max. resolution 1920 x 1200 @ 60 Hz

External Connectors

1 x D-Sub
1 x LAN (RJ45) port

Internal Connectors

8 x fan headers
1 x 6-pin PSU connector
1 x BMC header
1 x SPI header
1 x PM_BUS header
1 x USB 2.0 connector
1 x VGA header
1 x Panel header(links to PWR/RST header)
3 x Tr sensor headers
1 x BMC switch jumper
1 x VGA switch jumper
1 x LOC switch jumper
1 x BMC Indicator LED

Operating System

Windows 10 - 64 bit, Linux OS including Cent OS, Redhat, and Ubuntu

Accessories

1 x BMC cable
1 x SPI cable
1 x Power On/Off cable
1 x Reset cable
1 x USB 2.0 cable
1 x IPMI TPM ADAPTER
1 x User manual

Package Weight

0.3250 kg

Warranty

1 Year
