Asus ROG STRIX B760-I GAMING WIFI, Intel B760, 1700, Mini ITX, 2 DDR5, HDMI, DP, Wi-Fi 6E, 2.5G LAN, PCIe5, RGB, 2x M.2

Condition: New product

159 Item Items Warning: Last items in stock!

£ 227.42

Quantity

Data sheet

Manufacturer Number:	90MB1D90-M1EAY0
Manufacturer:	ASUS
Note:	Due to the different monitor and light effects, the actual color of the item might be slightly different from the color shown in the pictures. As for the dimensions, due to the measuring, please allow measuring deviations. Thank you!
Warehouse:	UK warehouse. Due to operating from different serviced warehouses, we cannot guarantee multiple items from the same order will be delivered together, although we try our best to do this.

More info

Motherboard Type

Desktop

Form Factor

Mini ITX

Socket

Intel 1700

Chipset

Intel B760

CPU Support

Click here for CPU support

RAM Technology

DDR5 (Dual Channel)

RAM Slots

2 x DIMM

RAM Speeds

Up to 7600(OC)

Maximum Memory

64GB

Graphics

Integrated Graphics*

*Graphics specifications may vary between CPU types

Graphics Ports

1 x HDMI
1 x DisplayPort

PCI/PCI Express

1 x PCIe 5.0 x16

Storage

4 x SATA III
1 x M.2 (2260/2280) - PCIe
1 x M.2 (2242/2260/2280) - PCIe

RAID

Intel Rapid Storage Technology supports SATA RAID 0/1/5/10

Wireless

Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band
Bluetooth v5.3

LAN

2.5GB LAN

Audio

ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A

USB Ports Supported

1 x USB 3.2 Gen2x2 Type-C (at back)
1 x USB 3.2 Gen1 Type-C (at back)
3 x USB 3.2 Gen1 Type-A (at back)
2 x USB 3.2 Gen1 (at mid-board)
5 x USB 2.0 (3 at back, 2 at mid-board)
1 x Front Panel Type-C USB 3.2 Gen2 Header

Back Panel I/O Ports

1 x USB 3.2 Gen2x2 Type-C
4 x USB 3.2 Gen1 (3 Type-A, 1 Type-C)
3 x USB 2.0
1 x HDMI
1 x DisplayPort
1 x Wi-Fi Module
1 x Intel 2.5Gb Ethernet
5 x Audio jacks

Internal I/O Connectors

1 x 4-pin CPU Fan
1 x 4-pin Chasis Fan
1 x 4-pin AIO Pump
1 x 24-pin Main
1 x 8-pin +12V
2 x M.2 (Key M)
4 x SATA 6Gb/s
1 x USB 3.2 Gen2 Type-C
1 x USB 3.2 Gen1
1 x USB 2.0
1 x Addressable Gen2
1 x Aura RGB

1 x Clear CMOS
1 x Front Panel Audio
1 x S/PDIF Out
1 x Speaker
1 x 10-1 pin System Panel
1 x Thermal Sensor

Accessories

2 x SATA 6Gb/s cables
1 x ROG USB2.0 splitter cable
1 x Panel cable
1 x Thermal pad for M.2
1 x ASUS Wi-Fi moving antennas
1 x Cable ties package
1 x M.2 Rubber Package
2 x Screw packages for M.2 SSD
1 x M.2 bracket
1 x ROG key chain

1 x ROG STRIX stickers
1 x ROG STRIX thank you card
1 x User manual

Additional Features

See Overview

Package Type

Retail

Package Weight

1.8900 kg

Warranty

3 Years

Full Box Quantity

Manufacturer Link

Click here for more details from the manufacturer
